產品資訊
| 項 次 | 型 號 | 尺寸規格 | 電壓/功率 | |||
| 發光面 | 發光面 | 中間 | ||||
| 長 度 | 寬 度 | 開孔 | ||||
| 1 | IF-FK195175-S46-X | 160 | 160 | Θ46 | 24V/6W | 24V/10W |
| 2 | IF-FK200180-S35-X | 190 | 150 | Θ35 | 24V/6W | 24V/12W |
| 3 | IF-FK224174-S35-X | 200 | 150 | Θ35 | 24V/6W | 24V/12W |
| 4 | IF-FK250200-S48-X | 235 | 185 | 48 | 24V/8W | 24V/15W |
| 5 | IF-FK320160-S48-X | 305 | 145 | 48 | 24V/10W | 24V/18W |
| 6 | IF-FK420420-S50-X | 400 | 360 | Θ50 | 24V/12W | 24V/20W |
| 7 | IF-FK430412-S30-X | 400 | 400 | Θ30 | 24V/12W | 24V/24W |
| 8 | IF-FK440316-S50-X | 400 | 300 | Θ50 | 24V/11W | 24V/20W |
| 9 | IF-FK460436-S50-X | 420 | 420 | Θ50 | 24V/14W | 24V/24W |
| 10 | IF-FK475475-S40-X | 460 | 460 | Θ40 | 24V/15W | 24V/28W |
| 11 | IF-FK523452-S40-X | 489 | 418 | Θ40 | 24V/16W | 24V/30W |
| 12 | IF-FK532516-S40-X | 500 | 500 | Θ40 | 24V/18W | 24V/36W |
| 13 | IF-FK550500-S40-X | 531 | 481 | 40 | 24V/18W | 24V/36W |
| 14 | IF-FK800800-S60-X | 780 | 780 | Θ60 | 24V/30W | 24V/54W |
| 15 | IF-FK920630-S50-X | 900 | 900 | Θ50 | 24V/32W | 24V/45W |
