產品資訊
| 項 次 | 型 號 | 尺寸規格 | 電壓/功率 |
燈珠 排數 |
寬 度 | |||
| 總長A |
發光 面長度B |
發光 面寬度 |
||||||
| 1 | IF-L6025-X | 60 | 48 | 15 | 24V/0.2W | 24V/0.4W | 3 | 25 |
| 2 | IF-L10825-X | 108 | 96 | 15 | 24V/1.5W | 24V/2.8W | ||
| 3 | IF-L15625-X | 156 | 144 | 15 | 24V/1.8W | 24V/3W | ||
| 4 | IF-L20425-X | 204 | 192 | 15 | 24V/2.8W | 24V/5W | ||
| 5 | IF-l25225-X | 252 | 240 | 15 | 24V/4.4W | 24V/8W | ||
| 6 | IF-l30025-X | 300 | 288 | 15 | 24V/5W | 24V/9W | ||
| 7 | IF-L39625-X | 396 | 384 | 15 | 24V/7W | 24V/12W | ||
| 8 | IF-L49225-X | 492 | 480 | 15 | 24V/8W | 24V/16W | ||
| 9 | IF-L58825-X | 588 | 576 | 15 | 24V/10W | 24V/18W | ||
| 10 | IF-L6040-X | 60 | 48 | 30 | 24V/0.3W | 24V/0.5W | 6 | 40 |
| 11 | IF-L10840-X | 108 | 96 | 30 | 24V/1.8W | 24V/3.2W | ||
| 12 | IF-L15640-X | 156 | 144 | 30 | 24V/2.2W | 24V/4W | ||
| 13 | IF-L20440-X | 204 | 192 | 30 | 24V/5W | 24V/8W | ||
| 14 | IF-L25240-X | 252 | 240 | 30 | 24V/6W | 24V/12W | ||
| 15 | IF-L30040-X | 300 | 288 | 30 | 24V/6.5W | 24V/12W | ||
| 16 | IF-L39640-X | 396 | 384 | 30 | 24V/8.5W | 24V/16W | ||
| 17 | IF-L49240-X | 492 | 480 | 30 | 24V/10W | 24V/18W | ||
| 18 | IF-L58840-X | 588 | 576 | 30 | 24V/12W | 24V/22W | ||
